Naraku Gasket Set for 52.4mm Cylinder Kit
Naraku Gasket Set for 52.4mm Cylinder Kit
$27.25
2 in stock
*Note: Free shipping to U.S. mainland (excludes AK, HI, and territories)
Orders placed by 1pm EST on weekdays ship the same day.
Product Details
Description
Naraku Gasket Set for 52.4mm Cylinder Kit
Key Details
- NK100.58
Additional information
| Weight | 0.3 lbs |
|---|---|
| Dimensions | 8.5 × 6.5 × 1 in |
Keep your Naraku 52.4mm Big Bore Kit sealed and running at full compression with this direct-replacement gasket set. Engineered specifically for the Naraku 89cc cylinder kit on QMB139 (1P39QMB) engines, it includes all three top-end gaskets needed for a cylinder service or rebuild. High-temperature composite and metal construction for reliable sealing under performance conditions.
This set is NOT compatible with stock 39mm (50cc) or 47mm (72cc/80cc) cylinders — verify your bore diameter before ordering.
This product is intended for off-road use only. This product is not intended for use on public roads or land.
- 3-piece gasket set engineered for Naraku 52.4mm 89cc big bore cylinder kits
- Includes head gasket (52.4mm bore), base gasket, and tensioner gasket
- High-temperature composite gaskets with metal head gasket ring
- Direct replacement for Naraku BBK top-end service on QMB139 engines
- Note: Packaging and non-metal gaskets may vary in appearance from product photo
- Bore size: 52.4mm (89cc displacement)
- Engine platform: QMB139 / 1P39QMB (GY6 50cc 4-stroke)
- Pieces: 3 (head gasket, base gasket, tensioner gasket)
- Material: High-temperature composite + metal head gasket
- Part number: NX100.58
- Brand: Naraku
| Make | Model | Notes |
|---|---|---|
| Generic / Chinese | QMB139 (GY50) 50cc — any brand | Must be equipped with Naraku 52.4mm BBK |
| Tao Motor / TaoTao | ATM50-A1 (Pony 50), Speedy 50, VIP Future Champion | Most common QMB139 platform for 89cc upgrades |
| Wolf Brand | RX-50, Islander 50, Blaze 50 | Standard QMB139 architecture |
| Ice Bear / Amigo | Rocket, Q6, Rocky, J-50 | 50cc short-case or long-case QMB139 engines |
| Honda | Metropolitan (2013+) | Only models converted to QMB139-style BBK |
| Kymco | Agility 50, People 50 | Compatible with 52.4mm engine conversions only |
