Athena 47.6mm Dio SR Performance Cylinder Kit

$197.99

Athena 47.6mm Dio SR Performance Cylinder Kit

1 in stock

UPC / ASIN 718046952428 / SKU: 135-1 Category: Tag:

Athena 47.6mm Honda Dio-SR Big Bore Cylinder and Head Kit. Kit includes cylinder, cylinder head, piston, ring, piston pin, cir clips, head gasket, base gasket and exhaust gasket. When you use this Athena 47.6mm Big Bore Kit in conjunction with your stock 41.4mm crankshaft you will increase your total displacement to 70cc!Fits Honda Elite S/SE/SR models from 1994-2001 and Kymco ZX50/Fever/DD50 models.Please see our Warranty & Returns Policy. *You may need to modify your engine case to accommodate the larger cylinder.

Weight 64 oz
Dimensions 6 × 6 × 8 in

  • Upgrades to 70cc

  • Aluminum Construction with Nickel Carbide Plated Bore
  • Cylinder Bore: 47.6mm
  • Cylinder Sleeve Outer Diameter: 53.5mm
  • Wrist Pin Diameter: 12mm
  • Total Piston Height: 49.5mm
  • Compression Height (from center of wrist pin hole to top edge of piston): 26mm
